| Brand Name : | 3U View |
| Model Number : | P2.5 |
| Certification : | TS16949 CE FCC 3C |
| Price : | Arguable |
| Payment Terms : | T/T, L/C, Western Union, MoneyGram |
| Supply Ability : | 2000/set/month |
| Delivery Time : | 3-25 working days after received your payment |
Anti-UV P2.5 Double-sided Taxi Top LED Display Car LED Anti-glaring Sign
Description
With the development of LED vehicle display technology, mobile advertising is more and more favored by global advertisers! The 3rd Double-sided Taxi Top LED Display integrates the latest technology of our company, which will increase your commercial advertising revenue. It can satisfy both large-scale and individuation. Choose 3U View as your partner, together make the future of DOOH!
Advantage
1. Taxi Top LED Display is a new mobile media platform that could display advertising and news coverage.
2. High reliability. 24h/7day advertising all the time and all weather conditions.
3. Low power consumption.12V DC input. Vehicle battery is enough to make the Taxi Top LED Sign work.
4. Different from traditional media, 3U View Taxi Top LED Display is able to switch advertising intelligently according to location and traffic information through the built-in GPS module.
Product Parameters
| Pixel Pitch | 2.5mm | Refresh Rate | 5120H |
| Display Size | 960*320mm | Viewing Angle | V140°H140° |
| Module Size | 320*320mm | Ingress Protection | IP56 |
| Module Resolution | 128*128 | Cabinet Material | Aluminium |
| Screen Resolution | 384*128*2 | Cabinet Color | Black |
| Cabinet Size | 1010(L)*386(H)*139(W)mm | Cabinet Weight | 18kg |
| Brightness | ≥5000cd/m2 | Control System | Android+4G+AP+WiFi+GPS+8GB Flash |
| Max.Power(≤W/set) | 380W | Supported Formats | JPG,GIF, BMP, WMF, MP4 |
| Ave.Power(≤W/set) | 120W | Environmental Requirements | Temperature: - 40℃~+80℃ Humidity: 10%~95%RH |
| Input Voltage | DC 9~36V | Driving Method | 1/16 |
| Output Voltage | DC 5V | Screen Lifespan | ＞100000 hours |
FAQ
Q: How to connect power cables?
A: The yellow wire is connected to the battery positive, the black wire is connected to the battery negative, and the white wire is connected to the cigarette lighter on the car.
Q: Why using three wires to control the screen?
A: In order to better protect the battery on the car, the extra white line is the trigger line, avoiding the screen is still operating after the vehicle shutdown, which will cause the loss of the car battery.
Q: What kind of luggage rack should be used for installation?
A: The rack should match your car. So you should tell us your car parameters, and measure the distance between the car roof mounting points.
We can provide the rack that match your car.
When a car enters a specific area with Taxi Top LED Display, the pointed commercial could automatically display the information.
Taxi Top LED Display consumes 120W on average, which is 50% less than traditional LED display power consumption.
Ingress protection rating up to 56. Together with the transparent PC cover. Taxi Top LED Display is totally weatherproof and shockproof.
|
